Aluminium Glass Railing with Rounded Edges

Send Inquiry

Request To Call Back

Aluminium Glass Railing with Rounded Edges

Price 1050 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

Aluminium Glass Railing with Rounded Edges Specification

Heat Resistance
Yes

Size
Height: 900mm to 1200mm standard; Length customizable

Material Composition %
Aluminium Alloy 6063: Al > 98%, Mg: 0.450.9%, Si: 0.20.6%

Recyclable
Yes, 100% recyclable materials

Hardness
Aluminium: 60-90 Brinell

Diameter
Handrail: usually 38-50 mm, customizable

Coating Type
Anodized / Powder Coated finish

Product Form
Modular railing system

Tensile Strength
Aluminium: 190-240 MPa; Glass: >100 MPa

Corrosion Resistant
Yes, excellent corrosion resistance due to anodized/powder coated surface

Product Name
Aluminium Glass Railing with Rounded Edges

Steel Type
Not Applicable (Aluminium as primary frame material)

Grade
Aluminium Grade 6063-T6 or equivalent

Thickness
Railing: 2-3 mm (Aluminium section), Glass: 10-12 mm (Tempered Glass)

Shape
Rectilinear with rounded edge profile

Surface
Smooth, Anodized or Powder Coated

Composition
Aluminium alloy frame and Tempered glass infill

Application
Balcony, Staircase, Terrace, Porch, Decks, Mezzanine Floors, Commercial Spaces, Residential Spaces

Dimension (L*W*H)
Customizable as per project requirements

Weight
Varies with dimensions; approx. 10-18 kg/meter

Color
Silver, Black, Custom RAL shades available

Material Grade
6063-T6 (Aluminium)

Finish Type
Matte/Glossy finish available

Usage
Indoor & outdoor safety barrier, decorative railing

Mounting Type
Floor mounted / Side mounted (customizable brackets)

Safety Standards
Meets EN1090/BS6180/ASTM E2358 or equivalent

Glass Edge Type
Polished and rounded (for safety and aesthetics)

Packaging
Protected with foam/polythene wrap and carton/crate for transport

UV Resistance
Yes, UV stabilized coatings available

Handrail Type
Aluminium rounded handrail; continuous or segmented

Maximum Span Between Posts
Up to 1200mm (depends on glass thickness and local standards)

Maintenance
Low maintenance; easy to clean with mild detergent

Glass Type
Tempered/Safety Glass

Glass Holder Type
Clamps, brackets, or slot-in track system

Installation
Pre-fabricated components for easy on-site assembly

Customizable Features
Color, dimensions, glass etching/printing, bracket style

About Aluminium Glass Railing with Rounded Edges

We VRail, Manufacturing Wide Range of Stainless Steel Railing, Glass Railing and Its Fittings. we have standard Grade for Stainless Steel SS304 and SS316, Its beautify your place with modular type railing Fittings with various finish options like Matt Finish, Glossy, Powder Coating, PVD Finish, Wooden Finish, Anodised Finish. Its Applicable for your residential House, Villas, Airports, Shopping Mall, Appartments and Many others.

Modern Safety Meets Design Versatility

Blending a minimalist aluminium frame with tempered glass panels, this railing system elevates any architectural project with a refined look. Rounded glass and handrail edges reduce hazard points while providing visual continuity. With customizable color, size, and decorative options, the system adapts to unique project needs and environments, from residential balconies to commercial terraces.

Engineered for Durability and Performance

Manufactured from premium 6063-T6 aluminium alloy paired with safety glass, this railing resists corrosion, heat, and UV weathering. Its anodized or powder-coated finish further extends its lifespan and minimizes maintenance needs. Meeting stringent global standards, it reliably supports maximum spans and withstands diverse environmental conditions.

Quick Installation and Effortless Maintenance

Delivered in modular, pre-fabricated units, the railing system offers straightforward on-site assembly with customizable floor or side mounting. Routine upkeep only requires mild detergent, owing to its smooth, non-porous surfaces. The thoughtfully engineered clamps or slot-in tracks facilitate secure, efficient installation and future adjustments if required.

FAQ's of Aluminium Glass Railing with Rounded Edges:

Q: How is the Aluminium Glass Railing with Rounded Edges installed on-site?

A: The railing system comes with pre-fabricated components and customizable brackets for either floor or side mounting. Installation involves simply assembling the modular parts according to provided instructions, securing the glass panels with clamps, brackets, or slot-in tracks. No specialized machinery is necessary, making assembly quick and convenient on most building sites.

Q: What types and thicknesses of glass are used in this railing system for safety?

A: This railing uses 10-12 mm thick tempered (safety) glass panels with polished and rounded edges to ensure both strength and a smooth, safe finish. It meets international safety standards such as EN1090, BS6180, and ASTM E2358 or their equivalents for reliable performance in high-traffic areas.

Q: Where can this modular railing system be used effectively?

A: The Aluminium Glass Railing is designed for versatile use across balconies, staircases, terraces, porches, decks, mezzanine floors, as well as both commercial and residential spaces. Its weather-resistant and corrosion-proof features make it suitable for both indoor and outdoor applications.

Q: What are the benefits of rounded edges and a continuous aluminium handrail?

A: Rounded glass and handrail edges not only enhance the visual appeal but also reduce the risk of injury by eliminating sharp corners. The continuous or segmented aluminium handrail provides a comfortable, secure grip, complementing the seamless look of the system.

Q: How do I maintain and clean the glass and aluminium surfaces?

A: Both glass and aluminium components require minimal maintenance. Regular cleaning with a soft cloth and mild detergent will keep the railing looking pristine. The anodized or powder-coated finish protects the frame from corrosion and staining, ensuring long-lasting brilliance with little effort.

Q: What customization options are available for this railing system?

A: You can customize color (including RAL shades), dimensions, glass etching or printing, bracket style, and handrail diameter. This ensures the railing perfectly matches your design, project requirements, and branding if necessary.

Q: What measures are taken to ensure product protection during shipping and installation?

A: Each component is wrapped in foam or polythene and packed within sturdy cartons or wooden crates, ensuring safe transportation and storage before installation.
