Aluminium Ramp Handrail for Accessibility

Price 1050 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

Aluminium Ramp Handrail for Accessibility Specification

Size
Custom as per project need (standard pipe diameter 40-50 mm; height 900-1100 mm)

Corrosion Resistant
Yes, high resistance due to anodized/powder-coated finish

Material Composition %
Al: 97-98%, Mg: 0.4-1.2%, Si: 0.3-0.8%

Product Form
Pipe/Rail, Modular Components

Tensile Strength
160-210 MPa (depends on grade)

Coating Type
Anodized / Powder Coated

Hardness
60-90 HB (Brinell)

Heat Resistance
Yes

Recyclable
Yes, fully recyclable aluminium

Diameter
Round: 40 mm, 50 mm (customizable)

Product Name
Aluminium Ramp Handrail for Accessibility

Steel Type
N/A (Aluminium Used)

Steel Product Type
N/A (Handrail, Aluminium)

Grade
6063-T5 / 6061-T6 (Typical Aluminium Grades)

Thickness
2 mm - 4 mm (customizable)

Shape
Round or Square Pipe/Rail

Surface
Anodized / Powder Coated

Composition
Aluminium Alloy

Application
Wheelchair Ramps, Accessibility, Handrail Support for Sloped Pathways, Public Infrastructure, Hospitals, Residential Buildings

Dimension (L*W*H)
Customizable (Typical: Length up to 3-6 meters per segment, Height 900-1100 mm, Diameter 40-50 mm)

Weight
Depends on length and configuration, typically 2.5-4.5 kg/meter

Color
Silver, Grey, Custom Colours Available

Material Grade
Industrial, Architectural Grade

Finish Type
Matte, Satin, Glossy (on request)

Usage
Support for Accessibility Ramps

Anti-slip Features
Compatible with tactile/warning strips on ramps

Handrail Height
900-1100 mm from finished surface

Custom Options
Length, color, finish, bends/angles as per site requirement

Accessories
End caps, wall brackets, corner joints as per layout

Baluster/Post Spacing
Maximum 1000 mm (center to center); customizable

Load Capacity
Designed for >1.6 kN/m (as per accessibility standards)

Packaging
Disassembled, packed in protective wrapping/carton

Maintenance
Low maintenance, easy to clean

Temperature Range
-20°C to +60°C operational

Installation
Surface-mounted base plates with anchoring bolts

Compliance
Meets ADA / local accessibility & safety codes (project adaptation required)

UV Resistant
Yes (with powder coated/anodized finish)

Joint Type
Mechanical fasteners or welded joints

About Aluminium Ramp Handrail for Accessibility

We VRail, Manufacturing Wide Range of Stainless Steel Railing, Glass Railing and Its Fittings. we have standard Grade for Stainless Steel SS304 and SS316, Its beautify your place with modular type railing Fittings with various finish options like Matt Finish, Glossy, Powder Coating, PVD Finish, Wooden Finish, Anodised Finish. Its Applicable for your residential House, Villas, Airports, Shopping Mall, Appartments and Many others.

Engineered for Accessibility and Safety

Our aluminium ramp handrail system adheres to ADA and local safety codes, offering reliable support on ramps and sloped pathways. With customizable height (9001100 mm), diameter, and layout, this handrail fits a wide range of accessibility needs. Each handrail segment is designed for strength (>1.6 kN/m load capacity), anti-slip compatibility, and seamless integration into any setting, making it ideal for hospitals, public infrastructure, and residential projects.

Superior Durability and Design Flexibility

Manufactured from industrial and architectural grade aluminium alloys, this handrail boasts excellent corrosion resistance, achieved through anodized or powder-coated finishes. Its UV-resistant surface endures harsh climates, while optional matte, satin, or glossy finishes suit diverse aesthetic preferences. Modular componentsincluding corner joints and end capsallow tailored installation based on project-specific ramps or stairways.

Effortless Installation and Low Maintenance

The system arrives in disassembled modules, complete with protective wrapping. Surface-mounted base plates and mechanical fasteners ensure straightforward, stable anchoring on all standard ramp surfaces. Maintenance is minimaljust routine cleaning with mild solutions keeps the handrail in optimal condition. Its design supports easy attachment of accessories such as tactile warning strips, further enhancing ramp safety and compliance.

FAQs of Aluminium Ramp Handrail for Accessibility:

Q: How is the aluminium ramp handrail installed?

A: The aluminium ramp handrail is surface-mounted using base plates and anchoring bolts. The system is supplied disassembled, allowing for easy on-site assembly, and includes all necessary fasteners and accessories.

Q: What customization options are available for this handrail?

A: You can customize the handrails length, color, finish (matte, satin, glossy), diameter (typically 40 or 50 mm), bends/angles, and height (within 9001100 mm). Layout and accessories like end caps or wall brackets are also tailored per site requirements.

Q: When would I need to consider local code requirements for installation?

A: While the handrail meets ADA and major accessibility codes, each site may have specific regulations. Project adaptation is required to comply with particular local codes, so consult with your local building authority before installation.

Q: Where can this handrail system be used?

A: The handrail is suitable for wheelchair ramps, sloped pathways, public infrastructure projects, hospitals, commercial buildings, and residential settings. Its durability and corrosion resistance make it ideal for both indoor and outdoor applications.

Q: What is the maintenance process for the aluminium handrail?

A: Maintenance is simple: just wipe the handrail with a damp cloth or mild detergent. The anodized or powder-coated surface resists dirt, graffiti, and weathering, reducing the need for intensive upkeep.

Q: How does this handrail improve ramp safety?

A: The handrail offers sturdy support, anti-slip compatibility with tactile/warning strips, and meets strength/load standards (>1.6 kN/m). Accessories like corner joints and end caps ensure a continuous, secure grip along the entire ramp.

Q: What are the main benefits of choosing this aluminium handrail over alternatives?

A: This handrail is lightweight yet strong, highly corrosion-resistant, fully recyclable, and customizable for various project dimensions and finishes. Its easy installation and low maintenance make it a cost-effective, long-term solution for accessible environments.
