anti-corrosion epoxy coating on aluminium handrails

Send Inquiry

Request To Call Back

anti-corrosion epoxy coating on aluminium handrails

Price 1050 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

anti-corrosion epoxy coating on aluminium handrails Specification

Technics
Epoxy Powder Coating Application

Style
Modern/Industrial

Color
Grey or customized shade as per RAL chart

Width
Variable, standard 40-50mm rail

Frame Material
Aluminium

Feature
Highly resistant to corrosion, durable, chemical and weather resistance

Arm Length
Custom or as per design

Gross Weight
Depends on handrail dimension

Open Style
Fixed / Wall-mounted

Size
Custom size, compatible with various rail diameters

Type
Handrail Protection Coating

Material
High-Grade Aluminium (substrate)

Surface Treatment
Anti-Corrosion Epoxy Coating

Height
Customizable (commonly 900mm - 1100mm)

Length
As per required site specifications

Processing
Surface Cleaned and Abrasive Blasted before Coating

Temperature Resistance
-30C to +120C post cure

Adhesion Strength
5 MPa (ASTM D4541)

Chemical Resistance
Excellent against acids, alkalis, salts, and solvents

Coating Thickness
Minimum 100 microns DFT (Dry Film Thickness)

Finish Appearance
Smooth, semi-gloss or matt as specified

VOC Content
Compliant with low VOC regulations

Pot Life
Typically 1 hour at 25C after mixing

Shelf Life
12 months in original, unopened container

Application Method
Electrostatic Spray or Roller/Brush

Curing Process
Thermal/oven cured at 180-200C

Coverage Rate
7-9 m/kg depending on surface profile

Environmental Compliance
RoHS and REACH compliant

Weather Resistance
Suitable for indoor and outdoor environments

Surface Preparation Standard
Complies with SSPC-SP 10/NACE No. 2 or ISO 8501-1 SA 2.5

About anti-corrosion epoxy coating on aluminium handrails

We VRail, Manufacturing Wide Range of Stainless Steel Railing, Glass Railing and Its Fittings. we have standard Grade for Stainless Steel SS304 and SS316, Its beautify your place with modular type railing Fittings with various finish options like Matt Finish, Glossy, Powder Coating, PVD Finish, Wooden Finish, Anodised Finish. Its Applicable for your residential House, Villas, Airports, Shopping Mall, Appartments and Many others.

Comprehensive Surface Protection

Our epoxy coating provides aluminium handrails with an advanced barrier against corrosion, chemicals, and environmental damage. It is engineered for long-term performance under demanding conditions, safeguarding metal surfaces and maintaining aesthetic appeal over time. Ideal for both residential and commercial industrial applications, it ensures enhanced durability for handrails exposed to varying temperatures and weather.

Precision Application, Lasting Quality

Thorough surface cleaning and abrasive blasting precede each application, ensuring exemplary adhesion and finish. With a minimum dry film thickness of 100 microns and a successful curing process at 180-200C, the coating achieves high mechanical strength and resistance to harsh agents. Flexible application options cover diverse project scales and custom design requirements.

FAQ's of anti-corrosion epoxy coating on aluminium handrails:

Q: How is the anti-corrosion epoxy coating applied to aluminium handrails?

A: The coating is applied by either electrostatic spray or with a roller/brush to thoroughly cleaned and abrasive-blasted surfaces. It is then thermally or oven-cured at 180-200C for optimal adhesion.

Q: What are the advantages of using this epoxy coating for handrails?

A: This coating offers high resistance to corrosion, chemicals, and weather, providing a smooth and durable finish. Its superior adhesion and compliance with environmental regulations make it suitable for indoor and outdoor installations.

Q: When should aluminium handrails be recoated or maintained?

A: Routine visual inspections are advised. Recoating frequency depends on environmental exposure, but the robust film thickness and chemical resistance extend intervals between maintenance cycles.

Q: Where can these coated aluminium handrails be installed?

A: They are ideal for areas demanding longevity, such as industrial plants, commercial buildings, residential complexes, hospitals, and outdoor spaces due to their weather and chemical resistance.

Q: What is the process involved in preparing surfaces before applying the epoxy coating?

A: Surfaces are thoroughly cleaned and abrasive blasted in line with SSPC-SP 10/NACE No. 2 or ISO 8501-1 SA 2.5 standards. This preparation ensures optimal coating adhesion and long-term protection.

Q: How does the coating perform with respect to environmental and safety standards?

A: Our epoxy system complies with RoHS, REACH, and low VOC regulations, making it safe for execution and sustainable for the environment.

Q: What finish and color options are available for these handrail coatings?

A: The finish can be specified as smooth, semi-gloss, or matt, and customized color options are available as per the RAL chart, matching varied architectural or branding requirements.
