commercial lobby staircase with steel handrails

Send Inquiry

Request To Call Back

commercial lobby staircase with steel handrails

Price 1050 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

commercial lobby staircase with steel handrails Specification

Coating Type
Frame: Epoxy/polyester powder paint, Handrails: None/clear lacquer

Corrosion Resistant
Yes, stainless steel and painted/coated steel

Material Composition %
Handrails: Fe 68%, Cr 18%, Ni 8%, Frame: Fe 98.5%, C 0.2%

Heat Resistance
Yes

Size
Standard/modular sizes; customizable

Product Form
Prefabricated staircase assembly

Hardness
Handrails: 150-200 HB, Frame: 120-180 HB

Diameter
Handrail diameter: 38-50 mm

Recyclable
Yes

Tensile Strength
Handrails: Min 520 MPa, Frame: Min 250 MPa

Product Name
Commercial Lobby Staircase with Steel Handrails

Steel Type
Structural Steel

Steel Product Type
Handrails and Frame

Grade
SS304/SS316 for handrails, Mild Steel for staircase frame

Thickness
Handrails 2-3 mm, Stringer 6-10 mm

Shape
Straight staircase with landing

Steel Standard
ASTM A36 for frame, ASTM A240 for handrails

Surface
Polished (Handrails), Painted or powder coated (Frame)

Composition
Handrails: Stainless Steel, Frame: Mild Steel

Application
Commercial lobby, office buildings, shopping malls, hotels

Dimension (L*W*H)
Customized as per site requirements (Example: L 6m x W 1.2m x H 3m)

Weight
Approx. 350-500 kg (depends on size/design)

Color
Handrails: Silver, Frame: Grey/Black

Material Grade
Handrails: SS304/SS316, Frame: IS2062

Finish Type
Handrails: Mirror/Brush polished, Frame: Smooth coated

Usage
Pedestrian traffic, public safety

Handrail Design
Round or Square profile, integrated with staircase

Load Capacity
5-10 kN/m²

Surface Treatment
Passivated for stainless steel, anti-rust for mild steel

Step Material
Steel, optionally covered with wood, stone, or tiles

Safety Features
Non-slip treads, continuous handrails, code-compliant railing height

Installation Method
On-site assembly with anchor bolts

Maintenance
Low, periodic cleaning recommended

Temperature Range
-20°C to +60°C operational

Fire Resistance
Meets international fire codes

Noise Insulation
Optional anti-vibration mounts

Baluster Spacing
< 100 mm as per safety codes

Accessibility
ADA-compliant design available

Edge Protection
Custom nosing profiles

Tread Depth
250-300 mm (as per design)

Stair Width
900 mm to 1800 mm (customizable)

Riser Height
150-180 mm (as per standard)

Handrail Height
900-1100 mm above tread

Environmental Compliance
RoHS & eco-friendly coatings available

About commercial lobby staircase with steel handrails

We VRail, Manufacturing Wide Range of Stainless Steel Railing, Glass Railing and Its Fittings. we have standard Grade for Stainless Steel SS304 and SS316, Its beautify your place with modular type railing Fittings with various finish options like Matt Finish, Glossy, Powder Coating, PVD Finish, Wooden Finish, Anodised Finish. Its Applicable for your residential House, Villas, Airports, Shopping Mall, Appartments and Many others.

Engineered Strength and Safety

Fabricated from structural mild steel and high-grade stainless steel, the staircase is designed to support significant pedestrian loads and withstand demanding use. Features such as continuous handrails, anti-slip treads, and code-compliant railing heights ensure optimal safety for all users. With a robust modular frame and stringent edge protection, it meets international fire and safety codes.

Flexible Design for Every Space

Custom sizes, profiles, and finishes allow seamless integration into a wide range of commercial interiors. Choose from mirror or brush-polished handrails, painted or powder-coated frames, and various tread finishes, including wood, stone, or tiles. Baluster spacing below 100 mm further enhances safety while maintaining a sleek, open aesthetic.

Low Maintenance, High Durability

Passivated and coated steel elements resist corrosion, rust, and heat, reducing upkeep requirements. Minimal periodic cleaning is sufficient for retaining structural and visual integrity. Optionally, anti-vibration mounts enhance noise insulation, ensuring quiet operation even during peak usage. The materials are fully recyclable and comply with RoHS and eco-friendly standards, supporting sustainable building practices.

FAQs of commercial lobby staircase with steel handrails:

Q: How is the Commercial Lobby Staircase with Steel Handrails installed on-site?

A: The staircase is assembled on-site using prefabricated modules and secured with anchor bolts to the building structure. All parts, including handrails and stringers, are precisely fabricated for easy assembly, ensuring structural integrity and adherence to safety standards.

Q: What types of handrail designs are available for this staircase?

A: You can choose between round or square handrail profiles, both crafted from high-grade SS304 or SS316 stainless steel. The handrails are mirror or brush polished, providing a modern look while also delivering durability and ease of maintenance.

Q: Where can this staircase system be used most effectively?

A: Optimized for commercial interiors such as lobbies, office buildings, malls, and hotels, the system is suitable wherever high pedestrian traffic and stringent safety standards are required. The customizable design and dimensions ensure a perfect fit for various architectural contexts.

Q: What process is followed to ensure compliance with fire and safety codes?

A: The staircase is constructed using code-compliant dimensions, materials with certified fire resistance, and safety features such as non-slip treads, continuous handrails, and baluster spacing below 100 mm. All components meet international standards like ASTM A36 and ASTM A240.

Q: How does the staircase benefit facilities in terms of accessibility and sustainability?

A: ADA-compliant design options provide improved accessibility for all users, while eco-friendly coatings and RoHS-compliant materials contribute to environmental sustainability. The structural components are fully recyclable, aligning with modern green building requirements.

Q: When is periodic maintenance required, and what does it involve?

A: Although maintenance is minimal, it is recommended to periodically clean the staircase using suitable cleaning agents, especially for the handrails and tread surfaces. Inspections for bolt tightness and coating integrity should be conducted as per facility schedules to ensure long-term performance.

Q: What options are available for noise reduction and tread finish?

A: For environments where noise control is essential, optional anti-vibration mounts can be integrated beneath the staircase assembly. Tread surfaces can be customized with wood, stone, or tile overlays, providing both aesthetic versatility and slip resistance.
