Sleek Aluminium Glass Railing

Price 1050 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

Sleek Aluminium Glass Railing Specification

Size
Height: 900-1200 mm typical; Length: Customizable

Product Form
Pre-fabricated straight and corner railing sections

Material Composition %
Aluminium 90-94%, Silicon 0.2-0.6%, Magnesium 0.45-0.9%, Glass 100% Silica base

Corrosion Resistant
Yes, highly resistant due to anodized/powder-coated finish

Hardness
Aluminium: 65-80 HB; Glass: 450-550 Knoop

Tensile Strength
Aluminium: min 160 MPa; Glass: up to 90 MPa

Diameter
Not applicable, uses rectangular/square profiles

Coating Type
Anodized or Powder Coated Aluminium

Heat Resistance
Yes

Recyclable
Yes, fully recyclable aluminium and glass

Product Name
Sleek Aluminium Glass Railing

Steel Type
Not applicable (Aluminium base)

Grade
6063-T5 Aluminium

Thickness
Glass: 10-12 mm; Aluminium: 2-3 mm

Shape
Rectangle Profile with flat and square lines

Surface
Glossy, polished aluminium with clear/tempered glass

Composition
Aluminium frame with toughened/tempered glass panels

Application
Residential and commercial balconies, staircases, terraces, and decks

Dimension (L*W*H)
Customizable as per site requirements

Weight
Approx 15-27 kg/m depending on dimension and glass thickness

Color
Silver, custom powder-coated colors available

Material Grade
Aluminium 6063-T5, Tempered Safety Glass

Finish Type
Glossy, Anodized or Powder Coated

Usage
Safety barrier, design accent, building exterior/interior

Frame Design
Concealed or visible fixation as per request

Maximum Panel Width
Up to 1200 mm per glass panel (site dependent)

Mounting Type
Top mounted or Side mounted

Installation
Modular, easy to assemble, minimal visible fasteners

Impact Resistance
Glass tested to withstand 1.5 kN/m horizontal load

Maintenance
Low-maintenance, wipe clean with gentle cleansers

Glass Type
Clear, Tempered or Laminated Safety Glass

Edge Type
Polished, rounded edges on glass panels

Wind Load Resistance
Engineered to meet standard wind loads for high rises

Handrail Option
With or without aluminium handrail

About Sleek Aluminium Glass Railing

We VRail, Manufacturing Wide Range of Stainless Steel Railing, Glass Railing and Its Fittings. we have standard Grade for Stainless Steel SS304 and SS316, Its beautify your place with modular type railing Fittings with various finish options like Matt Finish, Glossy, Powder Coating, PVD Finish, Wooden Finish, Anodised Finish. Its Applicable for your residential House, Villas, Airports, Shopping Mall, Appartments and Many others.

Contemporary Design Meets Robust Engineering

The Sleek Aluminium Glass Railing system is meticulously crafted to blend cutting-edge aesthetics with practical performance. Its clean lines, polished edges, and customizable features make it a standout choice for modern buildings. Engineered wind and impact resistance ensure safety for high-rise installations, while modular, prefabricated components provide flexibility and speed during assembly.

Customizable to Suit Every Space

Tailored to fit site-specific lengths, heights, and configurations, this railing system adapts to a wide range of architectural projects. From residential balconies to expansive commercial terraces, the system accommodates glass thicknesses of 10-12 mm and supports maximum panel widths of 1200 mm, creating uninterrupted views and seamless transitions.

Low Maintenance & Long-Lasting Finish

Anodized or powder-coated aluminium profiles grant exceptional corrosion resistance and enduring visual appeal. Easy-to-clean glass panels, with their polished, rounded edges, require only gentle cleansers to maintain a pristine look, making the system well-suited for both indoor and outdoor applications.

FAQ's of Sleek Aluminium Glass Railing:

Q: How is the Sleek Aluminium Glass Railing installed?

A: The railing features a modular design that allows for straightforward assembly with minimal visible fasteners. It can be top mounted or side mounted to various substrates, and prefabricated straight or corner sections speed up onsite installation. The concealed or visible fixation methods can be selected based on design preference.

Q: What type of glass is used for safety and aesthetics?

A: You can select between clear, tempered safety glass or laminated safety glass, each with polished, rounded edges for safety and a modern look. Glass panels have been tested to withstand a 1.5 kN/m horizontal load, meeting rigorous safety standards for residential and commercial use.

Q: When should I consider using a handrail with my glass railing?

A: While the railing is structurally sound with or without a handrail, opting for an aluminium handrail can offer added ergonomic support and an extra layer of safety, especially in areas frequently used by children or elderly individuals.

Q: Where can this railing system be installed?

A: This system is suitable for both interior and exterior applications on balconies, staircases, terraces, and decks. It is engineered to withstand standard wind loads required for high-rise buildings and is customizable to fit a variety of architectural contexts.

Q: What is the maintenance process for this railing?

A: Maintaining the Sleek Aluminium Glass Railing is hassle-free. Simply wipe the anodized or powder-coated aluminium and glass panels with a non-abrasive cloth and gentle, non-acidic detergents. Regular maintenance ensures the railing remains corrosion-resistant and visually appealing.

Q: How does this railing benefit my building project?

A: The system offers safety certification, a customizable aesthetic, and quick installation with minimal visible hardware. Its corrosion-resistant materials and modern, sleek design provide a durable, long-lasting accent that enhances property value and occupant security.
