SS Railing with Glass Panels

Price 1050 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

SS Railing with Glass Panels Specification

Hardness
SS: 160-220 HB

Diameter
SS Pipe: 38.1 mm, 50.8 mm or custom

Corrosion Resistant
Yes, suitable for indoor and outdoor use

Recyclable
Yes

Material Composition %
Chromium 18-20%, Nickel 8-10% (Steel); Silicon, Sodium, Calcium (Glass)

Coating Type
Optional Epoxy, Powder Coating or PVD

Product Form
Assembled railing system

Size
Modular/custom sizes available

Heat Resistance
Yes

Tensile Strength
Stainless Steel: 520 MPa minimum

Product Name
SS Railing with Glass Panels

Steel Type
Stainless Steel

Steel Product Type
Railing System

Grade
304 / 316

Thickness
Glass: 8-12 mm; SS pipe: 1.5-2 mm

Shape
Round or Square posts with flat or round handrails

Steel Standard
ASTM A240/A276

Surface
Mirror or Satin finish

Composition
SS Glass railing comprising stainless steel and tempered glass

Application
Balconies, Staircases, Terrace, Interior and Exterior spaces

Dimension (L*W*H)
Customizable as per requirement, Standard height 900-1100 mm

Weight
Varies by design and size; typically 10-20 kg/meter

Color
Silver (SS), Transparent (Glass)

Material Grade
304 / 316 Stainless Steel

Finish Type
Glossy/Mirror/Satin

Usage
Residential, Commercial, Institutional

Handrail Profile
Round/Square/U-shaped

Attachment Method
Bolted or Welded joints

Glass Edge Type
Polished

Maintenance
Low; periodic cleaning recommended

UV Resistance
Glass: Yes

Seismic Resistance
Yes, if installed as per code

Packaging Type
Standard export packaging

Baluster Spacing
100-130 mm center to center

Glass Clamps Type
SS adjustable clamps

Mount Type
Floor, Side, or Fascia mounted

Installation
Semi-assembled, Ready to install

Glass Type
Tempered/Safety Glass

Environmental Compliance
ROHS/Reach compliant stainless steel

Load Bearing Capacity
120 kg/meter

About SS Railing with Glass Panels

We V-Rail, Manufacturing Stainless Steel Railing Spigot with best quality, we are using SS304 and SS316. Its a available in various pvdf color coating like Golden Color, Rose Gold Color, Black Color, Wooden color that looks very modular and attractive for your place.

Robust Design and Safety

This railing system features premium tempered glass panels surrounded by either round or square stainless steel balusters, ensuring exceptional safety and strength. With a load bearing capacity of 120 kg/meter and glass thickness options from 8-12 mm, the railings comply with international safety standards and are available in both mirror and satin surface finishes for added elegance.

Flexible Installation and Customization

Our SS Railing can be floor, side, or fascia mounted using bolted or welded joints. Dimensional flexibility allows adaptation to various spaces with standard heights between 900-1100 mm and modular/custom sizing according to your requirements. The semi-assembled form ensures quick on-site installation, saving labor costs and time.

Ideal for Diverse Environments

Engineered for balconies, staircases, terraces, and beyond, the glass panels are UV resistant, corrosion-resistant, and maintain clarity even under harsh weather. The stainless steel grade 304 or 316 ensures long-term performance both indoors and outdoors, making this solution appropriate for residential, commercial, and institutional uses.

FAQ's of SS Railing with Glass Panels:

Q: How is the SS Railing with Glass Panels installed?

A: The railing system is provided semi-assembled and is ready to install upon delivery. Depending on the project requirements, it can be floor, side, or fascia mounted using bolted or welded joints. Adjustable stainless steel glass clamps ensure a secure fit for the tempered/safety glass panels.

Q: What are the maintenance requirements for this railing system?

A: Minimal maintenance is needed. Regular cleaning with a damp cloth and mild detergent will preserve the gloss and transparency of the glass and the finish of the stainless steel components.

Q: When should I opt for Grade 316 over Grade 304 stainless steel?

A: Grade 316 stainless steel is recommended for coastal or highly corrosive environments due to its superior resistance to chloride corrosion. For most indoor and standard outdoor conditions, Grade 304 offers reliable durability and performance.

Q: Where can the SS Railing system be used effectively?

A: This modular railing system is suitable for balconies, staircases, terraces, and both interior and exterior applications in residential, commercial, or institutional spaces. Its weather and corrosion resistance ensure lasting integrity in any setting.

Q: What benefits does using tempered glass with polished edges bring to the railing system?

A: Tempered glass provides substantial impact resistance, ensuring safety in high-traffic areas, while polished edges offer a sleek, finished look and eliminate sharp surfaces for improved user safety.

Q: How customizable is the railing system in terms of dimensions and finish?

A: The system is modular, allowing for customized lengths, heights (standard 900-1100 mm), and handrail profiles (round, square, or U-shaped). Available in mirror, satin, epoxy, powder coating, or PVD finishes to match your decor and design preferences.

Q: What environmental and safety compliances does this product meet?

A: The railing system is ROHS/REACH compliant for stainless steel, features recyclable materials, and is designed to withstand seismic forces if installed as per code. It is also engineered to meet ASTM A240/A276 steel standards for safety and performance.
