V-Rail Glass Bracket - D Bracket for 12mm Glass

Send Inquiry

Request To Call Back

V-Rail Glass Bracket - D Bracket for 12mm Glass

Price 1050 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

V-Rail Glass Bracket - D Bracket for 12mm Glass Specification

Material Composition %
Cr: 1820%, Ni: 810%

Tensile Strength
515-620 MPa

Hardness
201 HB (max)

Coating Type
None (Stainless Steel Polished)

Heat Resistance
Yes

Product Form
Bracket

Corrosion Resistant
Yes

Size
For 12mm glass panels

Recyclable
Yes

Product Name
V-Rail Glass Bracket - D Bracket for 12mm Glass

Steel Type
Stainless Steel

Steel Product Type
Glass Bracket / Fitting

Grade
SS304/316

Thickness
Suitable for 12mm glass

Shape
D Bracket

Steel Standard
ASTM A240/A240M

Surface
Polished / Brushed

Composition
18/8 Chrome-Nickel Stainless Steel

Application
Glass railing systems, staircase handrail, balcony balustrade, partition systems

Dimension (L*W*H)
Approx. 65 x 45 x 25 mm

Weight
160 g (approx.)

Color
Silver

Material Grade
304/316

Finish Type
Satin/Glossy

Usage
Securing and supporting glass panels in railing assemblies

Mounting Type
Wall or surface mount with expansion bolts

Maintenance
Wipe with soft dry or wet cloth

Glass Compatibility
Tempered, laminated, clear, or frosted glass

Usage Environment
Indoor and outdoor

Edge Protection
Soft rubber pads inside bracket

Included Accessories
Mounting screws, gaskets, Allen key

Installation
Easy, no welding required

Load Capacity
Holds up to 50 kg

About V-Rail Glass Bracket - D Bracket for 12mm Glass

Features:
Strong stainless steel material and chroming finish.
Looks elegance with satin polished finish.
Adjustable for its suitable glass thickness with its rubber layers and micro-adjusting screw.

Specification:
100% Brand New
Material: Stainless Steel
Grade : SS304
Fit for Glass Thickness: For 12mm Glass

Install Step:

1. Put the rubber gaskets into the gap of glass clamp.
2. Insert the glass into the middle of rubber gaskets, then put the screw into the hole and tighten it using the hexagon screwdrivers.
3. The micro-adjusting screw is optional for use to make the connection tighter.

Package:
1 x Glass Bracket
2 x Screw

Premium Stainless Steel Composition

Manufactured from SS304 or SS316 stainless steel conforming to ASTM A240/A240M standards, this D Bracket showcases excellent durability, tensile strength (515-620 MPa), and corrosion resistance. The 18/8 chrome-nickel alloy guarantees resilience, making it appropriate for both interior and exterior installations where longevity is crucial.

Effortless Installation Process

V-Rail Glass Bracket installation is simple, requiring no complex tools or welding. The bracket includes expansion bolts, mounting screws, gaskets, and an Allen key. Simply attach it to the wall or surface, insert the glass, and secure with provided hardware. This allows professionals and DIY users alike to complete installations swiftly and efficiently.

Versatility and Application

Perfectly suited for a range of architectural applications, this bracket anchors glass in railing systems, staircases, balcony balustrades, and partition walls. Compatible with 12mm tempered or laminated glass, its polished or satin finish enhances both contemporary and classic design environments. Ideal for builders, architects, and homeowners seeking reliable, aesthetic support for glass fixtures.

FAQ's of V-Rail Glass Bracket - D Bracket for 12mm Glass:

Q: How is the V-Rail Glass Bracket installed?

A: Installation involves securing the bracket onto the wall or surface using the included expansion bolts and screws. The glass panel rests within the D bracket, cushioned by soft rubber pads, and is tightened using the provided Allen key, requiring no welding or specialized equipment.

Q: What types of glass are compatible with this bracket?

A: This bracket is designed for 12mm thick tempered, laminated, clear, or frosted glass, ensuring flexibility for various architectural and interior designs.

Q: Where can I use the V-Rail Glass Bracket?

A: The bracket is suitable for both indoor and outdoor settings, including glass railing systems, staircase handrails, balcony balustrades, and partition systems in homes, offices, and commercial spaces.

Q: What benefits does the stainless steel construction provide?

A: Constructed from high-quality SS304/316 stainless steel, the bracket offers excellent corrosion and heat resistance, high tensile strength, and an attractive, easy-to-maintain finish-ensuring lasting durability and minimal upkeep.

Q: How do I maintain the V-Rail Glass Bracket?

A: Simply wipe the bracket with a soft, dry or wet cloth to maintain its shine and prevent buildup of dust or grime. No special cleaners or coatings are required due to the naturally resilient stainless steel.

Q: What is the load capacity and safety feature for glass panels?

A: Each bracket can support up to 50 kg and features soft rubber pads inside the bracket to protect glass edges from chipping and impact, enhancing both safety and product lifespan.

Q: Is the V-Rail Glass Bracket suitable for DIY installation?

A: Yes, the straightforward installation process, with all necessary accessories included, makes it ideal for both professional installers and DIY users.
