Weatherproof Aluminium Glass Railing

Name: Weatherproof Aluminium Glass Railing
Brand: Vishwakarma Engineering
Price: 1050 INR
Availability: InStock

Price 1050 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

Weatherproof Aluminium Glass Railing Specification

Tensile Strength
Aluminium: 215 MPa (min); Glass: 120 MPa

Coating Type
Anodized or Powder Coated (Aluminium), None (Glass)

Material Composition %
Aluminium 95%, Magnesium & Silicon 5% (Profile); 100% Tempered Glass (Panel)

Hardness
Aluminium: 73 Brinell

Diameter
Handrail: 4050 mm (if round)

Corrosion Resistant
Yes, High, due to anodized/powder-coated surfaces

Size
Custom sizes available

Recyclable
Yes, both aluminium and glass

Product Form
Modular Railing System with Glass Insert

Heat Resistance
Yes

Product Name
Weatherproof Aluminium Glass Railing

Steel Type
Not Applicable (Uses Aluminium for Profiles/Posts; Stainless Steel for Hardware if required)

Grade
Aluminium Grade 6063-T6; Glass: Tempered Safety Glass

Thickness
Aluminium Profile: 23 mm; Glass Panel: 1012 mm

Steel Standard
Not Applicable; Aluminium Profiles meet ASTM B221

Surface
Smooth/Matte Anodized/Brushed; Polished Glass

Composition
Aluminium alloy 6063, Tempered Glass, Stainless Steel Fittings

Application
Balconies, Staircases, Terraces, Patios, Decks, Outdoor and Indoor Railings

Dimension (L*W*H)
Customizable; Standard panel size: 1200 mm x 950 mm x 50 mm

Weight
Approximately 1218 kg per meter, varies with specification

Color
Silver, Black, White, or Custom Powder Coated

Material Grade
6063-T6 Aluminium; Tempered Glass Grade A

Finish Type
Matte, Satin, Glossy (Customizable)

Usage
Residential, Commercial, Outdoor and Indoor Spaces

Mounting Type
Side, Fascia, or Top Mount

Alignment Adjustment
Built-in adjustment for panel levelness

Installation
Bolt-on modular system for easy installation

Wind Load Resistance
Up to 1.5 kN/m

Edge Protection
Glass panels with polished/smooth edges

Glass Type
Clear, Frosted, Tinted, or Laminated Tempered Glass

UV Protection
Yes, for powder coating and glass

Maintenance
Low, requires occasional cleaning

Compliance Standards
Complies with international balustrade safety standards

About Weatherproof Aluminium Glass Railing

We VRail, Manufacturing Wide Range of Stainless Steel Railing, Glass Railing and Its Fittings. we have standard Grade for Stainless Steel SS304 and SS316, Its beautify your place with modular type railing Fittings with various finish options like Matt Finish, Glossy, Powder Coating, PVD Finish, Wooden Finish, Anodised Finish. Its Applicable for your residential House, Villas, Airports, Shopping Mall, Appartments and Many others.

Versatile Design and Superior Durability

This modular aluminium glass railing system combines elegant design with robust performance. Its corrosion-resistant, powder-coated aluminium profiles, and weatherproof tempered glass panels withstand harsh climates, making it suitable for outdoor or indoor installation. Maintenance is minimal, requiring only occasional cleaning, while the systems heat stability and UV protection ensure long-lasting clarity and color.

Easy Installation and Customizable Options

Installation is simplified with a bolt-on, modular system supporting side, fascia, or top mounting. Built-in adjustment mechanisms allow for effortless panel alignment and levelness. Panels and profiles are available in multiple finishesmatte, satin, or glossyin standard or custom colors, and in modular sizes to fit project requirements. Suitable for balconies, staircases, terraces, and beyond.

Safety, Compliance, and Environmental Benefits

Safety features include child-safe smooth glass edges, high wind load resistance (up to 1.5 kN/m), and compliance with international balustrade standards. Made from recyclable Grade 6063-T6 aluminium and toughened safety glass, the system is environmentally responsible. Stainless steel fittings further enhance structural integrity for residential and commercial applications alike.

FAQs of Weatherproof Aluminium Glass Railing:

Q: How is the Weatherproof Aluminium Glass Railing installed, and what mounting options are available?

A: This railing system utilizes a bolt-on modular design that enables quick and easy installation. You can choose from side, fascia, or top mounting options, depending on your architectural needs and space constraints. Built-in adjustment features ensure panels are aligned precisely.

Q: What types of glass are supported, and which finish options can I select?

A: You can specify clear, frosted, tinted, or laminated tempered safety glass panels, all with polished, smooth edges. Aluminium profiles are available in matte, satin, or glossy finishes and can be powder coated in silver, black, white, or other custom colors to suit your aesthetic preferences.

Q: When should I clean or maintain the railing system, and what does maintenance involve?

A: Maintenance is minimalan occasional cleaning with mild detergent and water helps retain the appearance of both aluminium and glass surfaces. Thanks to quality powder coating and anodized finishes, regular maintenance is not necessary for corrosion prevention.

Q: Where can this modular railing system be installed?

A: The railing system is versatile and ideal for balconies, staircases, terraces, patios, decks, and both outdoor and indoor railings. It fits residential and commercial environments and performs reliably in diverse conditions, from coastal climates to urban spaces.

Q: What are the safety features and compliance certifications of this product?

A: This modular railing meets international balustrade safety standards and is engineered to resist wind loads up to 1.5 kN/m. Panels are made from Grade A tempered safety glass with smooth edges, and profiles use high-grade 6063-T6 aluminium for added security and structural integrity.

Q: How does this system benefit the environment?

A: All major componentsaluminium and glassare fully recyclable. The powder-coated and anodized surfaces not only extend product lifespan but also reduce environmental impact by minimizing the need for frequent replacements or harsh chemical treatments.
