glass-compatible railing with round pipe posts

Send Inquiry

Request To Call Back

glass-compatible railing with round pipe posts

Price 1050 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

glass-compatible railing with round pipe posts Specification

Recyclable
Yes

Diameter
Post diameter: 38 mm / 50.8 mm / 63.5 mm (as per design)

Product Form
Modular Railing Kit

Heat Resistance
Yes

Coating Type
Optional powder coating available

Material Composition %
18% Chromium, 8% Nickel (for 304 SS)

Hardness
201 HB (Brinell, typical for SS304)

Tensile Strength
>= 485 MPa

Size
Customizable

Corrosion Resistant
Yes

Product Name
Glass-Compatible Railing with Round Pipe Posts

Steel Type
Stainless Steel

Steel Product Type
Railing System

Grade
SS304/SS316

Thickness
1.5 mm - 2.5 mm (pipe wall thickness)

Shape
Round Pipe Posts

Steel Standard
ASTM A240/EN 10088

Surface
Brushed/Polished

Composition
Stainless Steel and Tempered Glass

Application
Balconies, staircases, terraces, decks, patios, swimming pool fences

Dimension (L*W*H)
Customized as per site requirements

Weight
Depends on installation length and material

Color
Natural steel (silver) or customizable powder coating

Material Grade
AISI 304/316

Finish Type
Satin, Mirror, or Matte

Usage
Indoor and outdoor safety railing solution

Custom Options
Available in various finishes and post diameters

Post Spacing
Typically 900 mm to 1200 mm center-to-center

Glass Holding Type
Glass clamps or slot tube system

UV Resistance
Excellent UV resistance for outdoor use

Maintenance
Low maintenance, easy to clean surface

Mounting Type
Floor mount, side mount, or top mount options available

Compliance
Meets international safety and quality standards (EN, ASTM)

Installation
Supplied with mounting hardware and glass supports

Glass Compatibility
Suitable for 8 mm to 16 mm tempered and laminated glass panels

Height
Standard railing height: 900 mm to 1100 mm

About glass-compatible railing with round pipe posts

We VRail, Manufacturing Wide Range of Stainless Steel Railing, Glass Railing and Its Fittings. we have standard Grade for Stainless Steel SS304 and SS316, Its beautify your place with modular type railing Fittings with various finish options like Matt Finish, Glossy, Powder Coating, PVD Finish, Wooden Finish, Anodised Finish. Its Applicable for your residential House, Villas, Airports, Shopping Mall, Appartments and Many others.

Versatile Glass Compatibility

This railing system accommodates tempered and laminated glass panels ranging from 8 mm to 16 mm in thickness. The secure glass clamps or slot tube system ensure reliable holding, making it ideal for residential and commercial use, from staircases to pool fencing.

Superior Durability and Resistance

Crafted from high-grade stainless steel (SS304/SS316), the system offers outstanding corrosion, heat, and UV resistance. Its robust structure meets international safety standards, providing lasting performance with minimal maintenance-perfect for demanding outdoor and indoor environments.

Customizable Design and Easy Installation

With options for floor, side, or top mounting, and a variety of finishes, post diameters, and sizes, this railing kit adapts to any architectural style. Delivered as a modular kit with all necessary hardware, installation is straightforward and tailored to site-specific requirements.

FAQ's of glass-compatible railing with round pipe posts:

Q: How do I choose the right glass panel thickness for my railing installation?

A: The railing system is compatible with glass panels ranging from 8 mm to 16 mm thickness. Selecting the appropriate thickness depends on your specific structural requirements, safety needs, and local building codes. For high-traffic or outdoor areas, higher thicknesses are often recommended for added strength.

Q: What are the mounting options available for this railing system?

A: You can install the railing using floor mount, side mount, or top mount methods. The suitable mounting approach depends on your site conditions and aesthetic preferences, ensuring flexibility for balconies, decks, staircases, and other spaces.

Q: When should I use glass clamps versus the slot tube system?

A: Glass clamps are ideal for quick installations and offer easy replacement of glass panels. The slot tube system provides a seamless, continuous appearance and is recommended for premium designs or where higher glass retention is preferred.

Q: Where can this glass-compatible railing be installed?

A: This railing is suitable for a variety of indoor and outdoor settings-including balconies, staircases, terraces, decks, patios, and swimming pool fencing. It is designed to meet safety requirements across both residential and commercial applications.

Q: What is the installation process for the railing system?

A: The modular railing kit is supplied with all necessary mounting hardware and glass supports. Installation involves fixing the posts at pre-determined spacing (typically 900 mm to 1200 mm center-to-center), securing the glass panels with clamps or slot tubes, and finishing with the desired surface treatment.

Q: What are the key benefits of choosing stainless steel round pipe posts for glass railings?

A: Round pipe posts provide enhanced structural integrity, contemporary aesthetics, and great resistance to corrosion and UV exposure. Stainless steel's robust properties, along with customizable finishes, ensure longevity, minimal maintenance, and compatibility with diverse architectural styles.

Q: Is this glass railing system compliant with safety standards?

A: Yes, the railing system meets international quality and safety standards such as EN and ASTM. This ensures reliable performance, safety assurance, and suitability for export, distribution, and installation in multiple regions.
